Boiler Accessories

Industrial Chimney

Name: Industrial Chimney
Brand: Steamtherm Boilers Pvt. Ltd.

Safe, Efficient Flue Gas Discharge for Every Fuel Type.

The Steamtherm Industrial Chimney is engineered for the safe and efficient discharge of flue gases from boilers, thermic fluid heaters, hot air generators, furnaces, and other combustion equipment. Designed for durability, optimal draft, and compliance with environmental standards, our chimneys are available in self-supported, guy-wired, and structural-supported configurations.

Chimney Height10 to 60 Metres (or as required)

Diameter300 mm to 3000 mm

MaterialMild Steel (MS), Stainless Steel (SS304/SS316)

Design TemperatureUp to 600°C

Request a Quote

Technical Data

Technical Specifications

Chimney Height	10 to 60 Metres (or as required)
Diameter	300 mm to 3000 mm
Material	Mild Steel (MS), Stainless Steel (SS304/SS316)
Design Temperature	Up to 600°C
Fuel Compatibility	Biomass, Coal, Wood, Oil, Gas, LPG, PNG
Construction	Single Wall / Double Wall Insulated
Insulation	Mineral Wool / Rock Wool (Optional)
Surface Finish	Heat-Resistant Paint / Epoxy Coating
Mounting Type	Self-Supported, Guy-Wired, Structural-Supported

Key Features

Heavy-duty fabricated construction
Excellent corrosion resistance
High-temperature performance
Optimized flue gas draft
Low maintenance
Long service life
Weather-resistant finish
Easy installation and inspection
Designed for continuous industrial operation

Available Configurations

Self-Supported ChimneyGuy-Wired ChimneyStructural-Supported ChimneyDouble-Wall Insulated ChimneyStainless Steel ChimneyMulti-Flue Chimney

Optional Accessories

Access LadderSafety CageInspection DoorMaintenance PlatformAviation Warning LightLightning ProtectionRain CapExpansion JointFlange ConnectionsAnchor Bolts and Foundation Hardware
