Steam Boilers
COMBIPLUS
COMBIPLUS Series – Powerful Wood Fired Performance. Efficient Steam. Reliable Results.
The COMBIPLUS Series is a high-performance Manual Wood Fired Steam Boiler specially engineered for industries seeking an economical and reliable steam generation solution using wood and biomass fuels. Designed with advanced three-pass heat transfer technology, the COMBIPLUS Series delivers high thermal efficiency, stable steam output, and low operating costs. Its rugged construction and simple manual firing system ensure dependable performance, easy operation, and long service life.
Capacity Range1000 Kg/hr to 6000 Kg/hr
Working Pressure10.54 kg/cm²(g) to 17.5 kg/cm²(g)
Boiler TypeThree Pass Water-cum-Smoke Tube Type, Manual Fired Steam Boiler
Thermal Efficiency82% ± 2%
Technical Data
Technical Specifications
| Capacity Range | 1000 Kg/hr to 6000 Kg/hr |
|---|---|
| Working Pressure | 10.54 kg/cm²(g) to 17.5 kg/cm²(g) |
| Boiler Type | Three Pass Water-cum-Smoke Tube Type, Manual Fired Steam Boiler |
| Thermal Efficiency | 82% ± 2% |
| Construction | Package Type |
| Standards | IBR / Non-IBR Models Available |
Fuel Options
FirewoodWood LogsWood ChipsBiomass BriquettesSaw DustRice HuskAgro WasteBagasseBiomass Pellets
Key Features
- Three Pass Fully Wet Back Design
- High Thermal Efficiency (82% ± 2%)
- Manual Wood Fired Furnace
- Uniform Heat Distribution
- Low Fuel Consumption
- Large Furnace Volume
- Easy Fuel Charging & Ash Removal
- Rugged Heavy-Duty Construction
- Low Maintenance Cost
- Reliable 24×7 Steam Generation
- Long Equipment Service Life
Applications
Food Processing IndustryDairy IndustryTextile IndustryChemical IndustryPharmaceutical IndustryPaper & PackagingPlywood & LaminateRice MillsRubber & Plastic IndustryEngineering Industries
Advantages
- Economical Steam Generation
- Multi-Fuel Firing Capability
- Reduced Operating Cost
- Reliable Performance
- Easy Operation & Maintenance
- Environment-Friendly Biomass Fuel Utilization
- Long Service Life
